Tubis-X

.

Surface Mounted Downlight

Tubis-X

Offering exceptional efficiency of up to 100 lumens per watt, the Tubis X ensures a brilliant and energy-conscious illumination. Its deep-set optic not only enhances efficiency but also minimises glare, delivering a soft and inviting light ideal for various settings. Built to withstand exterior environments, its robust construction boasts an impressive IP65/IK08 rating, ensuring resilience against the elements. With multiple sizing and lumen packages available, the Tubis X Downlight caters to diverse heights and applications, making it a versatile and reliable choice for those seeking superior lighting solutions tailored to their specific needs.

OPTIONS/ACCESSORIES

  • DALI remote driver on request

As part of Novon’s ongoing efforts for sustainability and moving towards circularity, we carefully choose partners that align with and contribute to our values. Our solutions continually evolve, thanks to life cycle assessments (LCA) that minimise environmental impact. Choosing recycled materials for this range of luminaires, help reduce emissions during the manufacturing phase (A1-A4), targeting embedded carbon. Lamp promote decarbonisation with high energy efficiency solutions (<120 lm/W), minimising emissions during the usage phase (B6) and optimising installations with light and presence sensors.

Lamp’s primary product families in the Office segment possess Environmental Product Declarations (EPD), ensuring transparency in measuring the impact of our solutions throughout the building’s life cycle. Designed under eco-design criteria, these luminaires allow for repair, updates, and recyclability at the end of their life cycle.

Offering exceptional efficiency of up to 100 lumens per watt, the Tubis X ensures a brilliant and energy-conscious illumination. Its deep-set optic not only enhances efficiency but also minimises glare, delivering a soft and inviting light ideal for various settings. Built to withstand exterior environments, its robust construction boasts an impressive IP65/IK08 rating, ensuring resilience against the elements. With multiple sizing and lumen packages available, the Tubis X Downlight caters to diverse heights and applications, making it a versatile and reliable choice for those seeking superior lighting solutions tailored to their specific needs.

363mm Shallow Conical Shade - PET Felt
363mm Shallow Conical Shade - Cork

OPTIONS/ACCESSORIES

  • DALI remote driver on request

Technical Specs.

Luminaire source
LED SMD
Luminaire system wattage
10W ~ 40W
Luminaire luminous flux
900lm ~ 2700lm
Luminaire efficacy (avg.)
90lm/W, 100lm/W (4000K)
Correlated colour temp.
3000K
4000K
Colour rendering index
Ra≥90
Chromaticity tolerance
3
Unified Glare Rating
UGR ≥19
Service lifetime
>60,000h L70/B10
IP rating
IP65
Protection class
I
Finish
White
Black
Construction
Aluminium, tempered glass
Mounting / cutout
Ceiling surface
Warranty
5 Years
Luminaire termination
L/N/E terminal block internal termination
Lighting control
Non dimmable ECG standard; DALI dimming on request
Emergency classification
IK rating
IK08
Surge protection
Power factor
≥0.9
Operating voltage
220-240V AC, 50/60Hz
Operating temp.
-20º~45ºC

Non stocked item. Lead times apply

Beam Effect Options

Filters
Filters

Clear all

Showing 0 of 100
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.

Item Code

Family Variant

Mounting

Dimensions

Lumens

Power (w)

Optic

Distribution

CCT

CRI

IP

IK

Type

Finish

Control

Reflector

IES

Data Sheet

TUX1301893075B

Tubis-X 130

Surface

130

1800

18

Wide Flood

Direct

3000K

Ra>90

65

Black

Non-Dim

Specular

TUX1301893075BD

Tubis-X 130

Surface

130

1800

18

Wide Flood

Direct

3000K

Ra>90

65

Black

Dali

Specular

TUX1301893075W

Tubis-X 130

Surface

130

1800

18

Wide Flood

Direct

3000K

Ra>90

65

White

Non-Dim

Specular

TUX1301893075WD

Tubis-X 130

Surface

130

1800

18

Wide Flood

Direct

3000K

Ra>90

65

White

Dali

Specular

TUX1301894075B

Tubis-X 130

Surface

130

1800

18

Wide Flood

Direct

4000K

Ra>90

65

Black

Non-Dim

Specular

TUX1301894075BD

Tubis-X 130

Surface

130

1800

18

Wide Flood

Direct

4000K

Ra>90

65

Black

Dali

Specular

TUX1301894075W

Tubis-X 130

Surface

130

1800

18

Wide Flood

Direct

4000K

Ra>90

65

White

Non-Dim

Specular

TUX1301894075WD

Tubis-X 130

Surface

130

1800

18

Wide Flood

Direct

4000K

Ra>90

65

White

Dali

Specular

TUX1302593075B

Tubis-X 130

Surface

130

2500

25

Wide Flood

Direct

3000K

Ra>90

65

Black

Non-Dim

Specular

TUX1302593075BD

Tubis-X 130

Surface

130

2500

25

Wide Flood

Direct

3000K

Ra>90

65

Black

Dali

Specular

TUX1302593075W

Tubis-X 130

Surface

130

2500

25

Wide Flood

Direct

3000K

Ra>90

65

White

Non-Dim

Specular

TUX1302593075WD

Tubis-X 130

Surface

130

2500

25

Wide Flood

Direct

3000K

Ra>90

65

White

Dali

Specular

TUX1302594075B

Tubis-X 130

Surface

130

2500

25

Wide Flood

Direct

4000K

Ra>90

65

Black

Non-Dim

Specular

TUX1302594075BD

Tubis-X 130

Surface

130

2500

25

Wide Flood

Direct

4000K

Ra>90

65

Black

Dali

Specular

TUX1302594075W

Tubis-X 130

Surface

130

2500

25

Wide Flood

Direct

4000K

Ra>90

65

White

Non-Dim

Specular

TUX1302594075WD

Tubis-X 130

Surface

130

2500

25

Wide Flood

Direct

4000K

Ra>90

65

White

Dali

Specular

TUX1602593075B

Tubis-X 160

Surface

160

2500

25

Wide Flood

Direct

3000K

Ra>90

65

Black

Non-Dim

Specular

TUX1602593075BD

Tubis-X 160

Surface

160

2500

25

Wide Flood

Direct

3000K

Ra>90

65

Black

Dali

Specular

TUX1602593075W

Tubis-X 160

Surface

160

2500

25

Wide Flood

Direct

3000K

Ra>90

65

White

Non-Dim

Specular

TUX1602593075WD

Tubis-X 160

Surface

160

2500

25

Wide Flood

Direct

3000K

Ra>90

65

White

Dali

Specular

TUX1602594075B

Tubis-X 160

Surface

160

2500

25

Wide Flood

Direct

4000K

Ra>90

65

Black

Non-Dim

Specular

TUX1602594075BD

Tubis-X 160

Surface

160

2500

25

Wide Flood

Direct

4000K

Ra>90

65

Black

Dali

Specular

TUX1602594075W

Tubis-X 160

Surface

160

2500

25

Wide Flood

Direct

4000K

Ra>90

65

White

Non-Dim

Specular

TUX1602594075WD

Tubis-X 160

Surface

160

2500

25

Wide Flood

Direct

4000K

Ra>90

65

White

Dali

Specular

TUX1603093075B

Tubis-X 160

Surface

160

3000

30

Wide Flood

Direct

3000K

Ra>90

65

Black

Non-Dim

Specular

TUX1603093075BD

Tubis-X 160

Surface

160

3000

30

Wide Flood

Direct

3000K

Ra>90

65

Black

Dali

Specular

TUX1603093075W

Tubis-X 160

Surface

160

3000

30

Wide Flood

Direct

3000K

Ra>90

65

White

Non-Dim

Specular

TUX1603093075WD

Tubis-X 160

Surface

160

3000

30

Wide Flood

Direct

3000K

Ra>90

65

White

Dali

Specular

TUX1603094075B

Tubis-X 160

Surface

160

3000

30

Wide Flood

Direct

4000K

Ra>90

65

Black

Non-Dim

Specular

TUX1603094075BD

Tubis-X 160

Surface

160

3000

30

Wide Flood

Direct

4000K

Ra>90

65

Black

Dali

Specular

TUX1603094075W

Tubis-X 160

Surface

160

3000

30

Wide Flood

Direct

4000K

Ra>90

65

White

Non-Dim

Specular

TUX1603094075WD

Tubis-X 160

Surface

160

3000

30

Wide Flood

Direct

4000K

Ra>90

65

White

Dali

Specular

TUX2153593075B

Tubis-X 215

Surface

215

3500

35

Wide Flood

Direct

3000K

Ra>90

65

Black

Non-Dim

Specular

TUX2153593075BD

Tubis-X 215

Surface

215

3500

35

Wide Flood

Direct

3000K

Ra>90

65

Black

Dali

Specular

TUX2153593075W

Tubis-X 215

Surface

215

3500

35

Wide Flood

Direct

3000K

Ra>90

65

White

Non-Dim

Specular

TUX2153593075WD

Tubis-X 215

Surface

215

3500

35

Wide Flood

Direct

3000K

Ra>90

65

White

Dali

Specular

TUX2153594075B

Tubis-X 215

Surface

215

3500

35

Wide Flood

Direct

4000K

Ra>90

65

Black

Non-Dim

Specular

TUX2153594075BD

Tubis-X 215

Surface

215

3500

35

Wide Flood

Direct

4000K

Ra>90

65

Black

Dali

Specular

TUX2153594075W

Tubis-X 215

Surface

215

3500

35

Wide Flood

Direct

4000K

Ra>90

65

White

Non-Dim

Specular

TUX2153594075WD

Tubis-X 215

Surface

215

3500

35

Wide Flood

Direct

4000K

Ra>90

65

White

Dali

Specular

TUX2154093075B

Tubis-X 215

Surface

215

4000

40

Wide Flood

Direct

3000K

Ra>90

65

Black

Non-Dim

Specular

TUX2154093075BD

Tubis-X 215

Surface

215

4000

40

Wide Flood

Direct

3000K

Ra>90

65

Black

Dali

Specular

TUX2154093075W

Tubis-X 215

Surface

215

4000

40

Wide Flood

Direct

3000K

Ra>90

65

White

Non-Dim

Specular

TUX2154093075WD

Tubis-X 215

Surface

215

4000

40

Wide Flood

Direct

3000K

Ra>90

65

White

Dali

Specular

TUX2154094075B

Tubis-X 215

Surface

215

4000

40

Wide Flood

Direct

4000K

Ra>90

65

Black

Non-Dim

Specular

TUX2154094075BD

Tubis-X 215

Surface

215

4000

40

Wide Flood

Direct

4000K

Ra>90

65

Black

Dali

Specular

TUX2154094075W

Tubis-X 215

Surface

215

4000

40

Wide Flood

Direct

4000K

Ra>90

65

White

Non-Dim

Specular

TUX2154094075WD

Tubis-X 215

Surface

215

4000

40

Wide Flood

Direct

4000K

Ra>90

65

White

Dali

Specular

TUX901093075B

Tubis-X 90

Surface

90

1000

10

Wide Flood

Direct

3000K

Ra>90

65

Black

Non-Dim

Specular

TUX901093075BD

Tubis-X 90

Surface

90

1000

10

Wide Flood

Direct

3000K

Ra>90

65

Black

Dali

Specular

TUX901093075W

Tubis-X 90

Surface

90

1000

10

Wide Flood

Direct

3000K

Ra>90

65

White

Non-Dim

Specular

TUX901093075WD

Tubis-X 90

Surface

90

1000

10

Wide Flood

Direct

3000K

Ra>90

65

White

Dali

Specular

TUX901094075B

Tubis-X 90

Surface

90

1000

10

Wide Flood

Direct

4000K

Ra>90

65

Black

Non-Dim

Specular

TUX901094075BD

Tubis-X 90

Surface

90

1000

10

Wide Flood

Direct

4000K

Ra>90

65

Black

Dali

Specular

TUX901094075W

Tubis-X 90

Surface

90

1000

10

Wide Flood

Direct

4000K

Ra>90

65

White

Non-Dim

Specular

TUX901094075WD

Tubis-X 90

Surface

90

1000

10

Wide Flood

Direct

4000K

Ra>90

65

White

Dali

Specular

No items found.
No items found.
No items found.
No items found.
No items found.

*Refer to data sheet for technical data.

No results found.
There are no results with this criteria. Try changing your search.
