Viper Lux

.

Internal LED Batten

Viper Lux

The Viperlux Vandal Resistant Weatherproof Batten Light is designed to withstand the harshest environments while delivering exceptional performance. With a high ingress protection rating of IP66 and impact resistance rated at IK10, it provides unparalleled durability. This robust luminaire features a pressure die-cast LM6 aluminium housing, a UV-stabilised toughened polycarbonate diffuser, and anti-tamper screws, making it ideal for demanding industrial and public applications such as transport, correctional facilities, industrial sites, and high-vandalism areas. The Viperlux achieves a high efficacy of up to 125 lm/W and includes a removable gear tray for easy installation and maintenance. It also boasts a large 6mm terminal block and M20 cable entries, ensuring versatile connectivity. With superior lumen maintenance of ≥55,000 hours at L90/B10, the Viperlux offers reliable, long-lasting illumination.

OPTIONS/ACCESSORIES

  • Other CCT and tuneable white on request
  • DALI, DSI and other dimming on request
  • Emergency and DALI emergency on request Inbuilt multi-level microwave sensor
  • Surface mount bracket kit on request
  • Stainless steel M20 cable gland on request

As part of Novon’s ongoing efforts for sustainability and moving towards circularity, we carefully choose partners that align with and contribute to our values. Our solutions continually evolve, thanks to life cycle assessments (LCA) that minimise environmental impact. Choosing recycled materials for this range of luminaires, help reduce emissions during the manufacturing phase (A1-A4), targeting embedded carbon. Lamp promote decarbonisation with high energy efficiency solutions (<120 lm/W), minimising emissions during the usage phase (B6) and optimising installations with light and presence sensors.

Lamp’s primary product families in the Office segment possess Environmental Product Declarations (EPD), ensuring transparency in measuring the impact of our solutions throughout the building’s life cycle. Designed under eco-design criteria, these luminaires allow for repair, updates, and recyclability at the end of their life cycle.

The Viperlux Vandal Resistant Weatherproof Batten Light is designed to withstand the harshest environments while delivering exceptional performance. With a high ingress protection rating of IP66 and impact resistance rated at IK10, it provides unparalleled durability. This robust luminaire features a pressure die-cast LM6 aluminium housing, a UV-stabilised toughened polycarbonate diffuser, and anti-tamper screws, making it ideal for demanding industrial and public applications such as transport, correctional facilities, industrial sites, and high-vandalism areas. The Viperlux achieves a high efficacy of up to 125 lm/W and includes a removable gear tray for easy installation and maintenance. It also boasts a large 6mm terminal block and M20 cable entries, ensuring versatile connectivity. With superior lumen maintenance of ≥55,000 hours at L90/B10, the Viperlux offers reliable, long-lasting illumination.

363mm Shallow Conical Shade - PET Felt
363mm Shallow Conical Shade - Cork

OPTIONS/ACCESSORIES

  • Other CCT and tuneable white on request
  • DALI, DSI and other dimming on request
  • Emergency and DALI emergency on request Inbuilt multi-level microwave sensor
  • Surface mount bracket kit on request
  • Stainless steel M20 cable gland on request

Technical Specs.

Luminaire source
LED SMD
Luminaire system wattage
18W ~ 50W
Luminaire luminous flux
2200lm ~ 6100lm
Luminaire efficacy (avg.)
125lm/W (4000K)
Correlated colour temp.
4000K
Colour rendering index
Ra≥80
Chromaticity tolerance
3
Unified Glare Rating
Service lifetime
≥55,000h L90/B10
IP rating
IP66
Protection class
I
Finish
Grey­­
Construction
Die-cast aluminium, polycarbonate & stainless steel
Mounting / cutout
No items found.
Warranty
5 years (1 year emergency battery)
Luminaire termination
L/N/E internal termination
Lighting control
Non dimmable standard
Emergency classification
IK rating
IK10
Surge protection
Power factor
≥0.90
Operating voltage
220-240V AC, 50/60Hz
Operating temp.
-20º~45ºC (Emergency 0º~45ºC)

Non stocked item. Lead times apply

Beam Effect Options

Filters
Filters

Clear all

Showing 0 of 100
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.

Item Code

Family Variant

Mounting

Dimensions

Lumens

Power (w)

Optic

Distribution

CCT

CRI

IP

IK

Type

Finish

Control

Reflector

IES

Data Sheet

VIX00C11N

Viper Lux 700

Surface

698

3945

31

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00C84N

Viper Lux 700

Surface

698

3470

34

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00C88N

Viper Lux 700

Surface

698

3500

28

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00C91N

Viper Lux 700

Surface

698

3060

24

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00C93N

Viper Lux 700

Surface

698

2620

20

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00C94N

Viper Lux 700

Surface

698

2160

18

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00G13N

Viper Lux 1300

Surface

1305

4765

37

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00G60N

Viper Lux 1300

Surface

1305

7225

60

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00G70N

Viper Lux 1300

Surface

1305

6120

50

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00G74N

Viper Lux 1300

Surface

1305

5460

46

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00G85N

Viper Lux 1300

Surface

1305

4320

33

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00G87N

Viper Lux 1300

Surface

1305

3850

30

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00G88N

Viper Lux 1300

Surface

1305

3630

28

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00G91N

Viper Lux 1300

Surface

1305

3155

24

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00G93N

Viper Lux 1300

Surface

1305

2680

20

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX00G94N

Viper Lux 1300

Surface

1305

2210

18

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Non-Dim

VIX01C11N

Viper Lux 700

Surface

698

3945

31

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01C84N

Viper Lux 700

Surface

698

3470

34

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01C88N

Viper Lux 700

Surface

698

3500

28

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01C91N

Viper Lux 700

Surface

698

3060

24

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01C93N

Viper Lux 700

Surface

698

2620

20

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01C94N

Viper Lux 700

Surface

698

2160

18

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01G13N

Viper Lux 1300

Surface

1305

4765

37

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01G60N

Viper Lux 1300

Surface

1305

7225

60

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01G70N

Viper Lux 1300

Surface

1305

6120

50

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01G74N

Viper Lux 1300

Surface

1305

5460

46

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01G85N

Viper Lux 1300

Surface

1305

4320

33

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01G87N

Viper Lux 1300

Surface

1305

3850

30

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01G88N

Viper Lux 1300

Surface

1305

3630

28

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01G91N

Viper Lux 1300

Surface

1305

3155

24

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01G93N

Viper Lux 1300

Surface

1305

2680

20

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

VIX01G94N

Viper Lux 1300

Surface

1305

2210

18

Wide Flood

Direct

4000K

Ra>80

66

10

Grey

Dali

No items found.
No items found.
No items found.
No items found.
No items found.

*Refer to data sheet for technical data.

No results found.
There are no results with this criteria. Try changing your search.

Downloads

Product

Item

Download

Viper Lux

Family Brochure

Viper Lux

Data Overview

*Refer to data sheet for technical data.
